Built-in self-locking for safety and reliability: The reverse self-locking feature of the worm gear drive allows the attachment to remain fixed at any angle when stopped, preventing goods from sliding down without the need for an additional brake.
• Large reduction ratio and high output torque: Achieves a large transmission ratio in a compact structure, providing low-speed high-torque output to meet the rotation requirements of heavy goods.
• Compact structure and strong adaptability: Small size and light weight, can be directly installed between the forklift mast and attachment, suitable for 1-10 ton forklift attachments.
• Smooth operation with low noise: The worm gear meshing drive has low impact and low noise, ensuring smooth rotation and high control precision.
• Applicable Attachments: Forklift rotators, tilt forks, bale clamps, carton clamps, drum clamps and other attachments requiring rotation/tilting functions.
• Applicable Forklift Tonnage: 1 ton, 2 ton, 3 ton, 5 ton, 10 ton internal combustion/electric forklifts.
• Typical Applications: Food and beverage industry, warehousing logistics, waste recycling, chemical raw material handling and other scenarios requiring goods rotation.
• Regularly check the lubricating oil level and quality of the reducer, and replace the gear oil according to working conditions to avoid wear caused by oil shortage.
• Check the connecting bolts between the output flange and the attachment to prevent loosening that may cause abnormal noise or failure during rotation.
• Check whether the seals are aging and leaking to prevent dust and oil from entering the housing and causing corrosion.
• Avoid long-term overloaded continuous rotation to prevent overheating and accelerated wear of the worm gear.
