Applicable Fields:
• Construction Machinery: Truck cranes, aerial work platforms, excavator attachments, rotary drilling rigs, loaders with rotary devices
Renewable Energy: Single/double axis solar tracking systems, solar thermal reflector tracking platforms
• Security & Surveillance: Radar antenna rotary bases, high-speed PTZ cameras, monitoring pan-tilts
Port & Logistics: Container spreaders, stackers, port gantry crane rotary mechanisms
• Agricultural Machinery: Crop protection UAV landing platforms, orchard picking machinery, fertilizer spreaders
• Special Vehicles: RV rotary platforms, wrecker truck rotary arms, snowplow working devices
Features
• Superior Sealing Protection
Full-circumference rubber seal strips achieve IP65 (SE) / IP66 (WE) / IP67 (PE) protection ratings, effectively isolating dust, rain, and corrosive substances to extend service life.
• Integrated Design
Combines slewing bearing, worm gear, and motor/hydraulic motor mounting base into one unit, reducing assembly steps and structural complexity for equipment manufacturers.
• High Precision & Load Capacity
Quenched raceways (HRC55~62) and precision worm gear meshing enable ±0.03°~±0.3° rotation accuracy and support axial/radial forces & overturning moments for heavy-duty applications.
• Flexible Customization
Multiple transmission ratios (10:1~200:1), drive modes (DC/AC motor, hydraulic motor), and mounting forms (flange/base type) to meet personalized equipment requirements.
• Wide Temperature Adaptability
Operates stably in -40℃~+100℃ (PE series customizable), suitable for extreme cold/hot working conditions.
Comprehensive Competitive Advantage
• Quality Certification: ISO9001 quality management system certified, ensuring consistent product quality across the entire production process.
• Patented Technology: Own multiple patents for sealing structure and worm gear optimization, leading the industry in technical performance.
• CE Compliance: Meets EU Machinery Safety Directive and EMC standards, enabling seamless access to European and global markets.
• 8 Years of Expertise: Our R&D team with 20+ years of industry experience provides customized design and technical support for non-standard equipment.
• Efficient Production: Advanced CNC machining and automated assembly lines ensure short delivery cycles and high manufacturing precision.
