Applicable Fields:
• Industrial Automation: Collaborative robot rotary bases, automated production line rotary workstations, precision indexing tables
• Medical Equipment: Medical imaging equipment rotary frames, surgical robot positioning platforms, rehabilitation equipment rotary mechanisms
• Smart Logistics: AGV/AMR rotary lifting platforms, intelligent warehouse sorting machine rotary arms, logistics conveyor rotary nodes
• Light Machinery: Small CNC machine tool rotary tables, laser cutting machine rotary axes, 3D printing equipment rotary platforms
• Aerospace: Small satellite antenna rotary mounts, UAV ground station rotary platforms, aerospace test equipment positioning
• Consumer & Commercial: VR experience equipment rotary bases, commercial display turntables, smart home rotary mechanisms
Features
• Direct-Drive High Efficiency
Motor directly connects to the worm gear, reducing transmission links and energy loss, with a transmission efficiency of up to 92%—15% higher than traditional slewing drives with intermediate reducers.
• Ultra-Compact Design
Slim-type slewing bearing and integrated motor mounting base reduce the overall height by 30% compared with conventional models, suitable for equipment with limited installation space.
• Zero-Backlash Precision Positioning
Precision-ground worm gear pair with adjustable meshing clearance achieves ±0.02° rotation accuracy and zero-backlash transmission, meeting the high-precision positioning needs of automation and medical equipment.
• Dual-Seal Protection
Combined rubber seal strip and labyrinth seal structure reach IP65 protection rating, effectively preventing dust and liquid from entering, and suitable for clean rooms and outdoor light-duty working conditions.
• Low Noise & Low Vibration
Optimized worm gear tooth profile and precision machining reduce meshing noise to ≤55dB at rated speed, ensuring quiet operation of medical and office equipment.
• Easy Integration
Standardized flange mounting interface and motor connection flange are compatible with mainstream servo/stepper motors (24V/48V DC, 220V AC), enabling quick integration with host equipment.
Comprehensive Competitive Advantage
• ISO9001 Quality Certified: Full-process quality control from raw material machining to finished product testing ensures consistent product performance and reliability.
• Patented Direct-Drive Technology: Own patents for the integrated direct-drive structure and zero-backlash worm gear design, leading the industry in precision and compactness.
• CE & Medical Device Compliance: Complies with EU Machinery Safety Directive (CE) and medical device electromagnetic compatibility (EMC) standards, accessible to European and medical equipment markets.
• 8 Years of Precision Engineering: Our R&D team with 8+ years of experience in slewing drive design provides customized direct-drive solutions for special precision equipment.
• Fast Customization & Delivery: Modular production system supports quick customization of mounting dimensions and motor matching, with a lead time of 7–15 days for standard models.
